Human Cheek Epithilial Cells Stained With Methylene Blue 400xTM

Eukaryotic Cell
Parts, Functions & Diagrams
CLASS NOTES from Science Prof Online


Although there are differences among eukaryotes (creature that range from amoebae to elephant) overall, eukaryotic cells share many characteristics.
Here's a breakdown:

Eukaryotic Cell Envelope & External Structures
  • Cell Wall: The cells of plants, algae and fungi have thick, protective cell walls, which provide support, help maintain the shape of the cell, and prevent the cell from taking in too much fresh water and bursting.

Article Summary: Animals, plants, fungi, protists, algae, and water & slime molds are eukaryotes,  organisms composed of one or more nucleated cells. Here are the basics.
Eukaryotic Cell Structures, Functions & Diagrams
Virtual Cell Biology

You have free access to a large collection of materials used in a college-level introductory Cell Biology Course. The Virtual Cell Biology Classroom provides a wide range of free educational resources including Power Point Lectures, Study Guides, Review Questions and Practice Test Questions.
Endomembrane System of a Eukaryotic Cell, Mariana Ruiz
  • Endomembrane System: Organelles that are membranous have an additional handy feature, a built-in internal transportation system. Because membranous organelles are enclosed by the same type of material as the plasma membrane is made of (phospholipids and proteins), cellular supplies can easily be shipped when a piece of one membrane-bound organelle breaks off, forming a vesicle that travels within the cell, and then fuses with a different membrane-bound organelle. Material can also enter (endocytosis) or exit (exocytosis) the cell via this method.
  • Nucleus: The nucleus is typically the largest and most visible organelle in a eukaryotic cell. Bound by a double-layer nuclear membrane, the nucleus contains the cell’s genome—the main genetic instructions in the form of DNA (deoxyribonucleic acid).
  • Endoplasmic Reticulum: Functioning mainly as a factory for making and shipping proteins and lipids, the ER is a network of hollow tubes, extending off of the nuclear membrane. There are two types of ER, rough and smooth. Rough endoplasmic reticulum is covered with ribosomes, non-membrane-bound organelles which are the sites of protein synthesis within the cell. Smooth endoplasmic reticulum is not associated with ribosomes, and specializes in the synthesis and transport of lipids.
  • Golgi Body: These pancake-like stacks of vesicles as another type of factory within the cell. The Golgi body modifies cellular molecules and coordinates the packaging and shipment of materials out of the cell. It's also the only organelle that can generate lysosomes.
  • Lysosomes: This specialist vesicle contains lysozymes, enzymes that can degrade organic materials. They function in cellular digestion and recycling materials within the cell.
  • Peroxisomes: A type of specialist vesicle required by cells that use aerobic respiration (oxygen to extract energy from food) and made by the endoplasmic reticulum. Peroxisomes are armed with enzymes that break down dangerous oxygen free radicals.

Other Eukaryotic Cell Components and Organelles
  • Mitochondria: These tiny powerhouses of the cell, are double-membrane bound organelles that extract energy from food to produce ATP (adesnosine-5’- triphosphate), a multi-purpose molecule that carries energy for use within the cell.
  • Cytoplasm: The inside of the cell, between the nucleus and plasma membrane, is filled with a gel-like fluid in which the organelles are suspended. Cytoplasm includes both the liquid (called cytosol) and the suspended organelles.
  • Cytoskeleton: Composed of microtubules, intermediate filaments and microfilaments, this network of fibers provides an inner framework for the cell. The cytoskeleton supports the cells structure, anchors and helps transport organelles, and aids in cell division.
  • Microtubule Organizing Center (MTOC): This eukaryotic structure is where microtubules are assembled and anchored. In animal cells the MTOC is called the centrosome, which consists of two centrioles. In plant cells, the nuclear envelope appears to function as the main MTOC.

Drawing of a Plant Cell
Image of generic eukaryotic plant cell. For a labeled diagram of same cell, click here.
  • Cilia & Flagella: These extensions of the cell are covered with plasma membrane and supported internally with a structural system of microtubules—kind of like a bone covered in skin. Flagella, which are longer, and cilia, which are shorter, aid in cell movement. Cilia, which are able to beat together in a coordinated manner, can also help direct materials around the outside of the cell.

Eukaryotic Membrane-bound Organelles
The main distinction between prokaryotic and eukaryotic cells is the presence of membrane-bound organelles, a feature that only eukaryotes have. Organelles separate function within the eukaryotic cell, like a bunch of tiny, specialized factories that work together to help the cell run.
Endomembrane System Diagram by Mariana Ruiz
Image of eukaryotic endomembrane systeml. For a labeled diagram, click here.
Photos of prokaryotic & Eukaryotic Cells Button
facebook link
SPO twitter
Tamislinked in page
Page last updated 9/2014
SPO VIDEO: How to Make a Wet Mount of Stained Epithelial Cheek Cells
VIDEO: Watching movement of wax blobs in a lava lamp is an excellent way to help students understand how organelles of the eukaryotic endomembrane system ship materials into, out of and around within the cell.
Eukaryotic Cell Diagram and Function Homework Assignment
Here's our FREE
Eukaryotic Cell Homework Assignment!
Instructor's Corner
  • Plasma Membrane: All cells, both prokaryotic and eukaryotic, have a plasma membrane, made mainly of phospholipids and proteins, which functions as a barrier, regulating the movement of materials between the inside and the outside of the cell.

Tabellaria diatom algae @400xTM
Sources and Helpful Eukaryotic Cell Links
  • Becker, W. M. et. al. (2009) The World of the Cell. Pearson Benjamin Cummings.
  • Campbell, N. & Reece. J. (2002) Biology, Sixth Edition. Benjamin Cummings.

The SPO website is best viewed in Google Chrome or Apple Safari.
Animal Eukaryotic Cell, Mariana Ruiz
Image of generic animal cell. For labeled diagram of same cell, click here
For a practice assignment on diagramming  nimal cell click here.
