Mode of Action of
Penicillin Antibiotics





There are many different classes of antibiotics
each exerting a different type of inhibitory effect that specifically impacts bacteria. Bacterial cells are prokaryotic; primitive cells that differ significantly from humans’
eukaryotic cells.
Article Summary: Antibiotics are chemotherapeutic agents used to inhibit or kill bacteria. But how do penicillins (a type of beta-lactam) destroy these microbes without hurting our cells?
MOA of Penicillin (Beta-lactam) Antibiotics
​Page last updated: 4/2016

ANAT & PHYSGENERAL BIOCELL BIOMICRO 8wkMICRO 15wkINSTRUCTORS

SPO VIRTUAL CLASSROOMS
Antibiotic capsulesAntibiotic capsules
Antibiotic capsulesAntibiotic capsulesAntibiotic capsules
Antibiotic capsulesAntibiotic capsulesAntibiotic capsulesAntibiotic capsules
Antibiotic capsulesAntibiotic capsulesAntibiotic capsules
Antibiotic capsulesAntibiotic capsules
Antibiotic capsules
Antibiotic capsulesAntibiotic capsules
Beta-lactams exert their bactericidal effect by inhibiting the synthesis of the bacterial cell wall

Each article in this series covers a specific class of antibiotic and includes the following information:
Microbiology Main Page
  • list of the specific antibiotics that fall in the class (generic and brand names)
  • mode of action (how it works)
  • type of infections the antibiotic class is used against
  • type of bacteria inhibited or killed
  • pros and cons of using the class of antibiotics

Main Classes of Antibiotics
       (a Beta-lactam)
  • Penicillins (a Beta-lactam)
       (Fluoroquinolones)
       (Sulfa Drugs)

​Penicillin Antibiotics
In 1929 Alexander Fleming, a British biologist, inadvertently discovered penicillin. He had observed bacterial
Staphylococci colonies disappearing in cultures that were contaminated with mold.

Fleming eventually extracted the compound from the mold that had been responsible for destruction of the bacterial colonies. The product was named penicillin, after the Penicillium mold from which it was derived.

​Some examples of penicillins include:
  • amoxicillin
  • ampicillin
  • bacampicillin
  • oxacillin
  • penicillin

TSY agar inoculated with Staphylococcus. Three antibiotic sensitivity disks appear on this medium: penicillin, sulfa, and ciprofloxacin (clockwise from top). Note the "zone of inhibition" around each antibiotic disk. The larger the zone of bacterial inhibition, the more effective the antibiotic is against the bacteria.
Above: TSY agar inoculated with Staphylococcus
Gram-positive bacterium.

Three antibiotic sensitivity disks appear on this plate: penicillin, sulfa, and ciprofloxacin (clockwise from top).

Note the "zone of inhibition" around each antibiotic disk. The larger the zone of bacterial inhibition, the more effective the antibiotic is against the bacteria.
How a Microbiologist Cleans Her Kitchen
Penicillin core structure, where "R" is the variable group.
Penicillin core structure, where "R" is the variable group.
Continued ...
Go to PAGE 2 >
Infections Penicillins Are Used Against
Penicillins are used to treat Gram+ bacterial infections which, depending on the specific microbe involved, cause a wide range of illnesses including skin infections, dental infections, ear infections, respiratory tract infections, urinary tract infections, and gonorrhea.

A poster attached to a curbside mailbox offering advice to World War II servicemen: Penicillin cures gonorrhea in 4 hours.
About Us
CLASS NOTES
from the free STEM
education site
Science Prof Online
Mode of Action
Penicillins, and other beta-lactam antibiotics, work by interfering with interpeptide linking of peptidoglycan, the a strong, structural molecule found specifically bacterial cell walls. Cell walls without intact peptidoglycan cross-links are structurally weak, prone to collapse and disintegrate when the bacteria attempts to divide. Since the eukaryotic cells of humans do not have cell walls, our cells are not damaged by penicillins.

Antimicrobial Spectrum of Penicillins
Penicillins have a bacteriocidal effect on Gram-positive bacteria. In Gram-positive cells, peptidoglycan makes up as much as 90% of the thick, compact cell wall, and is the outermost layer.

Penicillins are not effective against Gram-negative bacteria, which have cell walls in which peptidoglycan is not the outermost layer, but that lies between the plasma membrane and a lipopolysaccharide (LPS) outer membrane. Penicillin cannot access the peptidoglycan of Gram-negative cells.

Alexander Fleming (1881 – 1955), the Scottish biologist & pharmacologist credited for discovering penicillin.
Alexander Fleming (1881 – 1955), the Scottish biologist & pharmacologist credited for discovering penicillin.
Plate of TSY Agar With Bacterial Samples from Dishes Before And After Dishwasher
HOME MICROBIOLOGY EXPERIMENT FROM SPO

Does the automatic dishwasher sanitize dishes? Yes!

TSY agar with sample from dirty dishes on top (note bacterial colonies that grew), and sample from cleaned dishes on bottom.
TSY agar inoculated with Escherichia coli,  a Gram-negative  bacterium. Three antibiotic sensitivity disks appear on this plate: penicillin, bacitracin and ciprofloxacin (clockwise from top).
Above: TSY agar inoculated with Escherichia coli
Gram-negative bacterium.

Three antibiotic sensitivity disks appear on this plate: penicillin, bacitracin and ciprofloxacin (clockwise from top).

Note the "zone of inhibition" only around the cipro. The larger the zone of bacterial inhibition, the more effective the antibiotic is against the bacteria.

This plate demonstrates that penicillin and bacitracin are not effective against Gram-negative bacteria.
Virtual Microbiology
Classroom






You have free access to a large collection of materials used in two college-level introductory microbiology courses (8-week & 16-week). The Virtual Microbiology Classroom provides a wide range of free educational resources including PowerPoint Lectures, Study Guides, Review Questions and Practice Test Questions.
